Solid Control
1

Drilling Mud Solids Control Equipment_Slurry Pump

DescriptionSubmersible Slurry Pump has vertical single stage and single suction system in overhung structure, adopting wear-resistant alloy material.
Download Pdf

Product Parameters

Product Parameters

Description

Submersible Slurry Pump has vertical single stage and single suction system in overhung structure, adopting wear-resistant alloy material. No bearing and shaft seal between the   impeller and the pump body, so it is free-maintenance, durable for high temperature,   then it is the ideal equipment to provide impetus for the decanter centrifuge.


Technical Parameters

Model
Flow(m3/h)Lift(m)Speed(rpm)Efficiency(%)Power(Kw)
50YZ20-1820181450423
50YZ40-104010.51450474
50YZ50-126010.81450555.5
80YZ50-2060181450487.5
80YZ80-20B8013.41450517.5
80YZ80-20A901514505111
100YZ100-301003114505422
100YZ100-30A1102414505418.5
100YZ160-38B1642614505030
150YZ250-40B2402414505037
150YZ250-40A2703014505145
